Tube pontoon jetty 8 x 3.2 m with 500 mm tube pontoons and steel frame! COMPLETELY READY!, Hirvensalmi

Rarely available! Quick sale!

High-quality 500 mm tube pontoon jetty built ready, deck section size 8 x 3.2 metres + gangway 5 x 1.2 metres.

Decking 28 x 120 mm green pressure-treated timber. Excellent for mooring even a large boat and for all kinds of leisure use.

The neatly made side cladding looks impressive.

The jetty has been on display in the water for approx. 2 months, so the decking has already weathered to grey and there may be minor marks.

Accessories included:

• Swimming ladder recess, V-shaped

• Swimming ladder 6 steps, folding (bright stainless steel) - incl. lifting lever (note! 4-step ladder shown in the picture)

• 3 pcs vertical mooring post, bright stainless steel

• 2 pcs F-hinges for fixing the gangway at the shore end

LONGITUDINAL FRAME 73 x 198 mm heavy-duty pressure-treated timber (the timbers are made from single pieces throughout) and transverse frame 80 x 80 mm hot-dip galvanised steel. In addition, the outer frame timbers are doubled on top of each other,

making the jetty extremely torsionally rigid.

The jetty price with accessories in our online shop is €10,700. We can store the jetty until May 2027!

If needed, we can arrange transport and installation for an additional fee. Also available with an aluminium-frame gangway for an extra charge.

Accessories such as swimming ladders can be found at LAATULAITURI.FI

* Total length: 13 metres (incl. gangway)
* Deck section size: 8 × 3.26 metres (length x width)

* Gangway size: 1.2 × 5.3 metres with roller wheels (incl. wear plywood)
* Tube pontoon diameter: Ø 500 mm
* Pontoon wall thickness: 12.3 mm

* Deck height above water level without load approx. 55 cm
* Length of tube pontoons in the deck section: 2 x 7800 mm + 1 support pontoon 1200 mm

* Transverse frame: 80 x 80 mm hot-dip galvanised steel (mounting flanges welded)

* Longitudinal frame: 73 x 198 mm heavy-duty pressure-treated timber (8 m long timbers - NOT made from sections)
* Deck: Pressure-treated board 28 × 120 mm green smooth - grade 2
* Deck boards fixed with stainless screws (NOT nailed)
* Gangway fitted with roller wheels

* Wear plywood under the gangway

* Side cladding with three boards (28 x 145 mm) - grade 2

* 4 anchoring loops
* Jetty and gangway delivered as ready-made elements

* Can also be installed in a T or L shape

• Swimming ladder recess, V-SHAPE

The pictures show accessories such as swimming ladders; these are available for an additional charge.
