New! Timco STIG250WSME AC/DC Pulse Inverter, with LCD! Lightweight, portable and compact TIG welder that welds almost all metals!, Orimattila

Sold new and unused directly from stock!

This product includes a 1 year warranty!

Timco STIG250WSME AC/DC Pulse Inverter

The Timco STIG250WSME is an LCD-equipped AC/DC pulse inverter — a lightweight, portable and very compact TIG welder that can weld almost all metals such as steel, stainless steel, chrome, titanium and aluminium!

With the latest technology and an LCD display, the Timco LCDTIG250WSME is an AC/DC pulse inverter that is light, portable and very compact. It is suitable for light industrial manufacturing, maintenance and repair, agriculture and the automotive industry. The LCDTIG250WSME is designed for high-quality TIG welding. It can weld almost all metals including steel, stainless steel, chrome, titanium and aluminium. When conditions are unfavourable for TIG, you can switch to stick welding using the electrode cables.

All TIG functions are adjustable, including start current, background current, end current, post-flow, pulse frequency, 2T/4T logic and more.

The tig torch's effective HF ignition ensures easy striking for both TIG and stick welding, making welding straightforward even for hobbyists.

Features:

• Can TIG-weld all materials, including aluminium

• LCD display with stepless current control

• Practical control panel

• Carrying handle

• Pulsed TIG function gives better control of the weld pool

• HF/LIFT TIG allows ignition with or without high frequency

• MMA (stick welding) works with most electrodes

• Note: you will also need a TIG electrode and a shielding gas cylinder (argon)

Technical specifications:

• Single phase: AC 230 V

• Rated current: 28 A

• Open-circuit voltage: 65 V

• MMA current range: 20 - 250 A

• TIG current range: 10 - 250 A

• AC pulse duty: 20-80 %

• Pulse duty: 10-90 %

• Post-flow: 1-10 s

• Pulse frequency: 0.5-5 Hz

• Remote control: Yes

• Arc: High frequency

• Efficiency: 85 %

• Duty cycle: 60 %

• Power factor: 0.93

• Insulation class: F

• Protection class: IP21

• Torch cable (TIG): 4 m

• Earth cable: 3 m

• Material thickness: 10 mm

• Dimensions: 480 x 240 x 400 mm

• Weight: 16 kg

• Standards: EN60974-1/3/10

Package includes:

• TIG cable 4 m

• 3 m electrode and earth cables for stick welding

• Wire brush

This product includes a 1 year warranty.

Delivery: Posti/Matkahuolto. Collection not possible.
