MAX model with extras of the popular Komator TB20 360° excavator - Ducar 15 hp petrol engine - grab thumb and 2 separate standard buckets, Lahti

Komator TB20G Max digging unit

MAX model with extras of the popular Komator TB20 360° excavator, powered by a reliable and efficient Ducar 15 hp petrol engine. The PRO model's equipment includes a grab thumb and two separate standard buckets: a 600 mm blade bucket and a 400 mm trenching bucket with teeth. The unit also has connections on the boom for hydraulic attachments such as an auger or grapple. The unit features a full 360° rotating structure for agile and efficient earthworks.

The Komator TB20G MAX ATV excavator has a maximum digging depth of 2.1 m and a digging radius of 2.8 m. The unit can be transported by ATV, tractors or other vehicles with a 50 mm tow hitch. During transport the stabiliser legs are folded to the horizontal position and, during operation, they are secured to the rear. The PRO model's additional mounts allow the axle width to be narrowed to 150 cm for easier trailer transport.

The unit is supplied with a boom thumb and two buckets and there is a wide range of optional attachments available to increase versatility, such as different buckets, an earth auger, frost spike and hydraulic hammer.

Technical specifications:

• Weight: 570 kg

• Power: 15 hp petrol engine (DUCAR, recoil start)

• Maximum digging depth: 2.1 m

• Maximum digging radius: 2.8 m

• Maximum digging height: 2.5 m

• Maximum loading height: 1.2 m

• Stabiliser width: 1.8 m

• Turning angle: 360 degrees

• Bucket rotation angle: 160 degrees

• Blade bucket width: 600 mm

• Trenching bucket width: 400 mm

• Wheelbase in transport position: 1500 mm

• Dimensions: 2240 x 1000 x 850 mm

• Warranty: 12 months

  Delivered unassembled in a transport frame.

Delivery: Home delivery or collection from Lahti.

Please note that collection requires the buyer to have suitable transport equipment. Collection must be arranged according to our warehouse schedules on weekdays. Loading is the customer's responsibility. Pickup instructions are available from our customer service. Our warehouse does not have a separate customer service point.
