MIG 200A FLUX MMA TIG LIFT welding machine, Isokyrö

MIG / MMA / TIG LIFT 200A WELDING MACHINE

Modern MIG welding machine designed for a wide range of uses – from workshop and service tasks to fieldwork and interior repairs. The unit combines a compact build with high performance, providing stable and precise operation in several welding modes.

The welding unit uses powerful IGBT transistors that convert 50/60 Hz to 20 kHz and then – using PWM technology – produce high-power voltage. This solution significantly reduces transformer size and weight while increasing the device efficiency by up to 30%. The advanced electronic control system allows precise control of current parameters, resulting in high-quality welds.

The model stands out with a stable wire feed speed, energy efficiency and absence of electromagnetic interference. Continuous and stable operation at low current makes the unit ideal for welding thin low-carbon, alloy and stainless steel sheets. Automatic compensation for supply voltage variations, low spatter levels, a stable welding arc and a high duty cycle ensure comfort and safety even during long-term use.

FEATURES:

✅ MIG FLUX / MMA / TIG LIFT inverter welding machine

✅ Modern IGBT technology – high efficiency and stable operation

✅ Compact design and light weight – easy to transport

✅ Stable wire feed speed and smooth welding arc

✅ Energy-saving operation and no electromagnetic interference

✅ Automatic compensation for input voltage variations ±15 %

✅ Protection against overvoltage, overcurrent and overheating

✅ Perfect for welding low-carbon, alloyed and stainless steels

✅ High duty cycle and good welding quality

TECHNICAL SPECIFICATIONS:

⚙️ Voltage: 220 V AC

⚙️ Frequency: 50/60 Hz

⚙️ Rated input capacity: 6.1 kVA

⚙️ Output current: 30–200 A

⚙️ Open-circuit voltage: 16–24 V

⚙️ Duty cycle: 60 %

⚙️ Wire speed: 3–15 m/min

⚙️ Gas flow: 15–20 l/min

⚙️ Dimensions: 325 × 153 × 237 mm

⚙️ Weight: 6.0 kg

Fast delivery (Matkahuolto)
