Now offered to the highest bidder: a high-quality electric loader. This model is widely used professionally in Europe. Agile to operate with a small turning radius, it is also suitable for smaller yards. Quiet operation!
Almost one year of the factory spare-parts warranty remains. Large manufacturer and guaranteed spare-parts availability. Several dealers in Europe.
- EURO implement attachment with hydraulic locks
- 5 kW electric motors on the front and rear axles
- Lifting capacity 635 kg
- Auxiliary hydraulics with quick couplings
- Steplessly adjustable hydraulic pump speed (via joystick)
- Cab with electric heater. Bluetooth radio and speakers in the cab.
- General-purpose bucket and multi-purpose bucket
- Two travel speeds (selected by a joystick button)
- Travel direction selected by a joystick button
- Tow hitch (50 mm ball)
- Hydraulically swivelling snow plough blade negotiable separately (request a quote)
Technical specifications
Bucket capacity: 0.25 m³
Rated load: 635 kg
Travel speed, low range: 10 km/h
Travel speed, high range: 20 km/h
Battery system: 72 V / 400 Ah
Battery capacity: 28.8 kWh
Battery type: Maintenance-free AGM lead-acid battery pack (12 × 12 V 200 Ah)
Charging time: 8 hours
Operating time: 4–6 hours, depending on workload
Drive motors: 2 × 4 kW (each axle has its own motor)
Tyres: 26×12.00-12 turf tread
Brakes: Hydraulic drum brakes
Hydraulic system:
Hydraulic system electric motor: 5 kW continuous power, steplessly adjustable via the joystick trigger
Hydraulic pressure: 16 MPa (160 bar) (can be increased to 180–200 bar)
Hydraulic flow, low range: 18.2 l/min
Hydraulic flow, high range: 50.3 l/min
Dimensions:
Gross weight: 2,050 kg
Maximum length with bucket lowered: 3.81 m
Overall width: 1.27 m
Bucket width: 1.16 m
Maximum bucket lift height: 3.33 m
Maximum dump height: 2.16 m
Height to top of cab: 2.26 m
Wheelbase: 1.37 m
Articulation angle: 45°
Turning radius: 2.13 m
