Demo unit at Lauttasaari shop — Element 7 S chartplotter with fishfinder and Northern Europe LightHouse chart (sensor not included), Helsinki

Demo unit on display at the Lauttasaari shop for sale. The Raymarine Element 7 S is a clear and reliable chartplotter, ideal for boating and fishing. The unit combines fast GPS navigation, a bright 17.8 cm (7-inch) screen and an internal CHIRP fishfinder that accurately shows bottom contours and water depth.

The Element S series is designed for boaters who value ease of use and performance. A powerful quad‑core processor ensures smooth operation and fast map updates. The included Northern Europe LightHouse chart helps navigate safely along coasts and inland waters. Please note this package does not include the transducer.

Key features

• 17.8 cm (7-inch) bright, weatherproof display

• fast and accurate 10 Hz GPS GNSS

• internal High CHIRP fishfinder support

• supports Raymarine LightHouse, Navionics and C-MAP charts

• RealBathy mapping for creating custom depth charts

• LightHouse Sport OS – easy-to-use operating system

• NMEA 2000 compatibility for expansions

• Wi‑Fi connectivity (2.4 GHz)

• programmable shortcut keys and clear menus

• compatible with Quantum radar




Technical specifications

• Model: Element 7 S

• Type: chartplotter and fishfinder (sensor not included)

• Display size: 17.8 cm (7-inch)

• Resolution: 800 x 480

• Display type: TN LCD

• Brightness: 1500 cd/m²

• Dimensions with mounting bracket: 263.85 x 162.59 x 149.40 mm

• Flush-fit dimensions: 239.60 x 135.10 x 149.40 mm

• Operating voltage: 8–16 V DC

• Power consumption: approx. 15 W

• Water rating: IPX6 and IPX7

• Operating temperature: -25 to +55 °C

• GPS: internal, 10 Hz

• GNSS: GPS, GLONASS, Beidou

• Memory card: 1 x microSDXC

• NMEA: NMEA 2000

• Wi‑Fi: 802.11 b/g/n 2.4 GHz

• Fishfinder: High CHIRP (requires transducer)

Package contents

• Element 7 display

• flush-fit gasket

• sun cover

• mounting bracket and fasteners

• documentation

• NMEA 2000 and power cable

• Northern Europe LightHouse chart (opened, used in demo unit)
