MIG 200A Welding Machine — FLUX / MMA / TIG LIFT, Isokyrö

MIG / MMA / TIG LIFT 200A WELDING MACHINE

Modern MIG welding machine designed for a wide range of uses – from workshop and maintenance tasks to fieldwork and indoor repairs. The unit combines a compact build with high performance and offers stable, precise operation in multiple welding modes.

The welder uses powerful IGBT transistors that convert 50/60 Hz to 20 kHz and then — using PWM technology — generate high-power voltage. This reduces transformer size and weight significantly while increasing efficiency by up to 30%. The advanced electronic control system enables precise control of current parameters, resulting in high-quality welds.

The model stands out for its stable wire-feed speed, energy efficiency and lack of electromagnetic interference. Continuous, stable operation at low current makes the unit ideal for welding thin low‑carbon, alloy and stainless steel sheets. Automatic compensation for supply voltage variations, low spatter levels, a stable arc and high duty cycle ensure comfort and safety even during prolonged use.

PRODUCT FEATURES:

✅ MIG FLUX / MMA / TIG LIFT inverter welder

✅ Modern IGBT technology – high efficiency and stable operation

✅ Compact design and light weight – easy to transport

✅ Stable wire-feed speed and smooth welding arc

✅ Energy-saving operation and no electromagnetic interference

✅ Automatic compensation of supply voltage variations ±15 %

✅ Protection against overvoltage, overcurrent and overheating

✅ Ideal for welding low‑carbon, alloy and stainless steels

✅ High duty cycle and good weld quality

TECHNICAL SPECIFICATIONS:

⚙️ Voltage: 220 V AC

⚙️ Frequency: 50/60 Hz

⚙️ Rated input capacity: 6.1 kVA

⚙️ Output current: 30–200 A

⚙️ Open-circuit voltage: 16–24 V

⚙️ Duty cycle: 60 %

⚙️ Wire speed: 3–15 m/min

⚙️ Gas flow: 15–20 l/min

⚙️ Dimensions: 325 × 153 × 237 mm

⚙️ Weight: 6.0 kg
