NEW Cartiwell CW-460 Track Loader, Kerava

ARRIVING IN STOCK IN JUNE 2026

Cartiwell CW-460

Colour: Green (Images may show different colours.)

The CW-460 track loader is a versatile work machine offering excellent performance. Its track design provides good traction and stable operation even in demanding terrain. The machine is equipped with an advanced hydraulic system delivering strong power and precise control for a variety of tasks.

Controls are user-friendly: the controls are clear and easy to use, improving operator comfort. A powerful engine enables long and efficient working periods.

The loader supports quick attachment changes, making it suitable for many tasks such as loading, digging and clearing. This increases the machine's versatility and improves productivity, making it an excellent choice for construction sites and maintenance work.

Technical specifications

Machine data

Engine brand: RATO

Rated power: 15–18 kW

Rated speed: 3600 rpm

Number of cylinders: 2

Air intake: Naturally aspirated

Displacement: 639 cm³

Emission class: Euro 5

CE marked

Rated operating load: 380 kg

Maximum operating load: 500 kg

Maximum breakout force: 450 kN

Bucket capacity: 0.12 m³

Travel speed: 0–6 km/h

Total cycle time: 9 s

System operating pressure: 17–21 bar

Fuel tank: 10 L

Operating weight: 1200 kg

Track size: 18 × 72

Dimensions

Height at maximum lift: 2450 mm

Height to bucket pin: 1870 mm

Machine height: 1350 mm

Maximum height with bucket level: 1810 mm

Length without attachments: 1680 mm

Length with standard bucket: 2206 mm

Maximum dumping angle: 34°

Dump height: 1510 mm

Dump reach: 450 mm

Bucket tilt angle on ground: 27°

Bucket tilt angle at top position: 114°

Wheelbase: 850 mm

Ground clearance: 150 mm

Rear overhang: 280 mm

Track width (standard tracks): 720 mm

Machine width (standard tracks): 960 mm

Bucket width: 1000 mm

Factory warranty 12 months
