Tool trolley with 541-piece tool set for professional use (FINAL), Isokyrö

Tool trolley with tools for professional use

Number of drawers: 12

Dimensions: 1120 x 480 x 995 mm

Weight: approx. 124 kg

PRODUCT DESCRIPTION AND FEATURES

The Kraft&Dele tool cabinet model KD1071 is an indispensable product for every body shop and workshop.
The cabinet is supplied with a tool set consisting of 541 pieces.

The cabinet is fitted with a rubber bumper to prevent accidental damage to the vehicle body during use.

The drawer locking system allows only one drawer to be opened at a time.


Each drawer runs on ball-bearing slides, making opening smooth, quiet and durable.

All tools are made from CrV steel (chrome–vanadium).

Large wheels with automatic locks and brakes ensure safety when moving the cabinet, even on slight inclines.

DIMENSIONS:

Height: 112 cm

Height: 99 cm

Width: 48 cm

Weight: approx. 124 kg

Contents
Middle drawer 1
Socket set with ratchet (186 pieces)

3 ratchets (72 teeth) - 1/4", 3/8", 1/2"
Torque wrench 1/2" 20–210 Nm (72 teeth)
1/4" handle screwdriver for sockets and bits
9 hex keys TYPE L - 1.5-2-2.5-3-4-5-6-8-10 mm
9 TORX keys TYPE L - T10-15-20-25-27-30-40-45-50
48 bits, 1/4" shank - SL4-5.5-6.5-7; PH0-1-2-3; PZ0-1-2-3; T8-9-10-15-20-25-27-30-40 TT8-9-10-15-20-25-27-30-40; TTS10-15-20-25-27-30-40-45-50; M8-10-12;
13 sockets 1/4" - 4-4.5-5-5.5-6-7-8-9-10-11-12-13-14 mm
24 bits 8 mm - SL8-10-12; PH3-4; PZ3-4; T40-45-50-55-60-70; H7-8-10-12-14; TT40-45-50-55-60-70
Socket adapter with 3/8" holder
17 sockets 3/8" - 6-7-8-9-10-11-12-13-14-15-16-17-18-19-20-21-22 mm
7 TORX-E sockets (star) 3/8" - E10-11-12-14-16-18-20
2 spark plug sockets 3/8" - 16 mm, 21 mm
18 bits, 1/2" drive - H14-H17-H19-M18*55L; R9-M9*100L; M16*100L; T80*100L; T40-T45-T50-T55-T60-T70*140L; R10*14 ; M10-M12-M14*140L
17 1/2" sockets - 10-11-12-13-14-15-16-17-18-19-20-21-22-24-27-30-32 mm
4 long impact sockets for alloy wheels - 17 mm, 19 mm, 21 mm, 22 mm
3 universal joints - 1/4", 3/8", 1/2"
6 extensions - 1/4"x50 mm, 1/4"x100 mm, 3/8"x75 mm, 3/8"x150 mm, 1/2"x125 mm, 1/2"x250 mm
3 ratchet handles with sliding square - 1/4", 3/8", 1/2"
1L - Left drawer 1
Wrench set (25 pcs)
12 offset ring spanners - 6 7 mm, 8 9 mm, 10 11 mm, 12 13 mm, 14 15 mm, 16 17 mm, 18 19 mm, 20 22 mm, 21 23 mm, 22 24 mm, 24 27 mm, 30 32 mm
13 TORX keys - T8-10-15-20-25-27-30-40-45-50-55-60-70
2L - Left drawer 2

Pliers (12 pcs)

Combination pliers 200 mm

Straight, narrow half-round pliers 200 mm

Side-cutting pliers 190 mm

Adjustable pliers 250 mm

Morse locking pliers 250 mm

Vernier caliper 0–150 mm

4 circlip pliers 150 mm

Telescopic pick-up with magnet

3 m tape measure

3L - Left drawer 3

Chisel and hammer set (20 pcs)

Locksmith hammer 300 g with wooden handle

40 mm panel hammer

Set of cutters and punches with rubber grip (18 pcs)

4L - Left drawer 4

Wrench set (31 pcs)

•
  21 combination spanners - 6-7-8-9-10-11-12-13-14-15-16-17-18-19-20-21-22-24-27-30-32 mm


•
  9 ratchet combination spanners - 8-9-10-11-12-13-14-17-19 mm


•
  Adjustable wrench 200 mm (8")


5L - Left drawer 5

T-handle key set (18 pcs)

•
  9 hex keys with swivel tip (ball) - H8x200, H7x150, H10x200, H6x150, H5x150, H4x150, H3x100, H2.5x100, H2x100


•
  9 TORX keys - T40x150, T45x200, T50x200, T10x100, T27x150, T15x100, T20x100, T25x150, T30x150


6L - Left drawer 6

Screwdriver set (21 pcs)

•
  7 Phillips screwdrivers - PH2*38 mm, PH0*75 mm, PH1*75 mm, PH2*100 mm, PH2*125 mm, PH3*150 mm, PH3*175 mm


•
  7 flat-tip screwdrivers - SL6*38 mm, SL3*75 mm, SL5*75 mm, SL6*100 mm, SL6*125 mm, SL8*150 mm, SL8*175 mm


•
  7 flat-tip drivers with hex shank - SL6*38, PH2*38, SL5*100, PH1*100, SL6*100, SL6*150, PH3*150


•


1P - Right drawer 1

Crimping pliers and terminals

· Connector set (160 pcs)

· Cable insulation stripper, crimper

2P - Right drawer 2

File set 200 mm (5 pcs)

•
  tapered flat file


•
  tapered triangular file


•
  tapered half-round file


•
  tapered round file


•
  tapered square file


3P - Right drawer 3

Impact socket set (28 pcs)

•
  14 short impact sockets - 8-9-10-11-12-13-14-15-16-17-19-21-22-24 mm


•
  14 long impact sockets - 8-9-10-11-12-13-14-15-16-17-19-21-22-24 mm


4P - Right drawer 4

T-handle socket set

•
  6 socket wrenches – 6-7-8-10-13-14 mm


5P - Right drawer 5

Oil service kit

•
  3/8" oil drain adapters – XT45-XT10-XS10-S7-S8-S10-S11-S12-S13-S14-S3/8-S5/16-M16-H8-H9-H10-H12-H13-H14 - H17


•
  3/8" square sliding handle


•
  Claw wrench for oil filters 58–110 mm 3/8"


•
  Claw wrench for oil filters 50–95 mm, three-arm 1/2"


•
  Belt-style strap wrench for oil filters 55–110 mm


•
  Reducer 1/2" > 3/8"


•
  Reducer 3/8" > 1/2"
