5 kW 12 V diesel/petrol engine water heater, Vantaa

Diesel/petrol water heater. The first start determines the fuel.

Features:

- Prevents vehicle damage caused by sudden temperature drops.

- Low noise: noise-damping treatment for minimal sound.

- Easy to install: compact design fits many tight spaces.

- Low fuel and power consumption for longer run times.

- Stable, automatic cabin-temperature control with preset temperature.

- Continuous monitoring and diagnostic system.

- Fuel is drawn from the vehicle's own tank.

- Suitable for various diesel mechanical vehicles such as cars, buses, motorhomes, trucks, service vehicles, etc.

Rumour has it someone has used one to provide hot water at a cottage :)

Technical specifications:

Heat output (W): 6,000 W

Fuel consumption (l/h): Diesel: 0.46 L/h, Petrol: 0.52 L/h

Permitted ambient temperature/altitude: -40 °C to 80 °C, altitude ≤ 6,000 m

Weight: 2.9 kg

Package includes:

1 x HVAC heater

1 x fuel hose (5 m)

1 x silencer

1 x exhaust pipe

1 x controller

1 x remote control

1 x fresh-air intake hose

1 x exhaust-air pipe

1 x fuel drain device

1 x oil filter

1 x air filter

1 x water pump

1 x oil pump

2 x oil pump clamps

1 x mounting plate

1 x remote control

1 set of screw accessories

1 set of nylon cable ties

1 set of threaded pipes

1 x main wiring harness

User manual: English

⚠️ Diesel heater safety instructions

The diesel heater's combustion process consumes oxygen and produces hazardous exhaust gases. Incorrect installation can lead to carbon monoxide poisoning or fire.

1. Exhaust routing (Main rule)

• Exhaust outside only: Exhaust gases must be routed completely outside the building, tent or vehicle using a metal exhaust pipe.

• Sealing: Ensure the exhaust connection to the heater body is sealed with the supplied clamp. Even a small leak into the interior can be fatal.

• CO alarm: Always install a good-quality carbon monoxide alarm in the space. It is inexpensive life insurance.




2. Exhaust temperature and insulation

The exhaust pipe becomes extremely hot in use.

• Max temperature: The diesel heater exhaust temperature at the outlet can reach 250–450 °C depending on power. The metal pipe itself may glow hot.

• Feed-through: If the exhaust passes through a wall or floor, use non-combustible insulation (e.g. rock wool or a separate metal feed-through sleeve). The pipe must not touch wood, plastic or other combustible materials directly.

• Clearance: Keep the exhaust pipe at least 10 cm away from any meltable or combustible materials along its length.




3. Combustion air and heated-air intake

• Separate air intakes: Ensure the heater's exhaust pipe is not near the heater's combustion-air intake or the heated-air intake. Otherwise the unit can draw its own exhaust back in.




4. Fuel handling

• Position the fuel tank so that in the event of a leak diesel cannot run onto the hot exhaust pipe.
