Electric winch 12V 1588 kg / 3500 lb, Isokyrö

12V electric winch is an ideal solution for ATVs, quads and buggies. High-quality materials and the excellent fit of all winch components make it perfect even in very harsh conditions such as off‑road use where water, mud and sand are common. The 153:1 planetary gearbox is made of high‑grade steel and has been heat‑treated to significantly extend its service life. Fitted with an automatic dynamic brake that stops the winch immediately in the event of a power cut. The winch is controlled by a cable or a radio remote.

Product features:

• made from highest‑quality materials

• ideal for off‑road enthusiasts; recommended for ATVs, quads and buggies

• precise component fit combined with a sealing system provides excellent protection against mud, water, snow and sand

• modern motor design provides 0.9 kW (1.2 hp) of power which, together with a 153:1 planetary gearbox, delivers 1588 kg of pulling force

• comfortable and easy‑to‑use clutch release lever

• dynamic automatic brake built into the drum

• durable steel rope, 4.8 mm diameter and 12 m length

• steel rope guide with two vertical and two horizontal rollers

Technical specifications:

Pulling capacity: 1588 kg (3500 lb)

Supply voltage: 12V

Motor power: 0.9 kW (1.2 hp)

Gearbox: planetary, spur

Reduction: 153:1

Rope length: 12 m

Rope diameter: 4.8 mm

Drum (diameter/length): 38 mm / 72 mm

Winch dimensions (L × H × D): 320 × 105 × 125 mm

Mounting hole distance: 80 mm
