Harvia Cilindro Plus SPOT electric sauna stove PP70SP, Pieksämäki

The Harvia Cilindro Plus SPOT® electric stove is supplied with the fully wireless Harvia SPOT® control switch with no visible cables.

The pillar stove is easy to turn on and off with a single press. The 6.8 kW stove is suitable for saunas of 6–10 m³.

The impressive pillar stove with a large stone capacity has a brushed stainless steel surface.

The Cilindro Plus pillar stove’s outer shell leaves plenty of the stone surface visible.

You can easily adjust the sharpness of the steam by pouring water directly onto the stone pillar or onto the side of the stove.

Heat distributes evenly thanks to the large stone surface.

The Cilindro Plus SPOT® PP70SP stove is fitted with a control unit integrated into the stove, which can be operated with the wireless illuminated SPOT® control switch.

The stove is quick and easy to switch on or off with a single press of the switch.

The control switch is splash-proof, so it can be installed in a bathroom or even in the immediate vicinity of the stove.

Placement of the SPOT® control switch can ensure, for example, that children cannot accidentally switch the stove on.

Using the switch is safe and reliable: the stove’s control lights illuminate when the stove is in use, and the illuminated indicator LEDs show operating or error status.

The controller has start-time settings for 2 h / 4 h / 6 h. The radio range of the control switch is approximately 5–10 m, depending on wall structure. The SPOT® control switch is battery powered.

TECHNICAL SPECIFICATION

• power: 6.8 kW

• sauna size: 6–10 m³

• max. stone amount: 90 kg

• width: 310 mm

• height: 1020 mm

• depth: 310 mm

• weight: 11.5 kg

• colour: steel

• supply voltage 3-phase: 400 V 3N~ (5 x 1.5 mm², 3 x 10 A)

• supply voltage 1-phase: 230 V 1N~ (3 x 6 mm², 1 x 35 A)

• minimum sauna height: 1900 mm

• installation: floor-mounted

• clearance to sides: 100 mm

• clearance to front: 100 mm

• clearance to ceiling: 880 mm

• clearance to floor: 20 mm

• battery-powered wireless control switch

Electrical connections for the stove must be made only by a qualified electrician. Observe the stove’s clearance distances during installation.
